Newtec MDM2210 - Status Bar LED Indicators

10/71
Modem Web Interface
MDM2210
User Manual R4.1 v1.0
4.4 Status Bar
4.4.1 Ethernet LED
The Ethernet LED gives the general status of the Ethernet connection to the modem.
LED Color Code
Description
Red
Connection is not OK.
Yellow
Connection is OK, but no DHCP address is given.
Green
A DHCP address is given and the connection is OK.
4.4.2 Wi-Fi LED
The Interface LED gives the general status of the Wi-Fi connection between the modem and a client
device.
LED Color Code
Description
Red
Connection is not OK.
Yellow
Connection is OK, but no DHCP address is given.
Green
A DHCP address is given and the connection is OK.
4.4.3 Satellite LED
The Satellite LED gives the general status of the Satellite connection to the modem.
LED Color Code
Description
Red
No connectivity, no valid signal received.
Yellow
A valid signal was received. The terminal is busy logging in on the satellite
network.
Green
The system is operational and the user is logged in on the satellite
network.
