Modem Web Interface
MDM2210
User Manual R4.1 v1.0
Parameter Description
• WPA-Mixed
Encryption Key Only displayed when an encryption method is selected (WEP or
WPA).
Enter an encryption key.
The default encryption key can be found on the product label.
WPA Cypher Only displayed when WPA is selected as encryption protocol.
• TKIP : Temporal Key Integrity Protocol
• CCMP : This protocol is more robust than TKIP.
Counter Mode with Cipher Block Chaining Message Authentication
Code Protocol
This is an encryption protocol that is based on the Advanced
Encryption Standard (AES).
• TKIP + CCMP: This is a combination of the previously explained
protocols.
4.7.3 Satellite Interface
This section describes the interface settings between the terminal and the satellite.
The satellite interface settings are predefined in factory.
These settings may only be changed upon advice of your
Service Provider!
A satellite beam covers a limited geographical area in which terminals are serviced by
the satellite.
The displayed satellite interface settings depend on the beam that was selected during
the terminal installation.
Refer to TerminalInstallationonpage16 for more information.
Every satellite interface setting consists of:
• Initial Receive Carrier
This is the initial receive carrier through which the modem will try to gain access to the network.
• Pointing Carrier
This carrier is needed to enable antenna pointing via the Point&Play mechanism. When two
different pointing carriers are assigned to the terminal, the installer can perform his pointing on
two different pointing carriers. At least one pointing carrier must be enabled.
Maximum two satellite interface settings per beam can be assigned to the terminal. This is for
redundancy or migration reasons. In case two initial receive and/or pointing carriers are assigned
to the terminal, one preferred carrier is marked.
In case no carrier setting is configured, no carrier setting is shown in the GUI.
