60/71
Modem Web Interface
MDM2210
User Manual R4.1 v1.0
The maximum number of TCP sessions is set by the Service Provider.
• If more than half the maximum allowed number of TCP sessions is active, a warning message is
displayed. In the example shown below, the maximum number was set to 500.
• If the number of active TCP sessions exceeds the maximum number set by the Service Provider,
an error message is displayed, TCP sessions will be delayed until the number drops again below
the maximum. In the example shown below, the maximum number was set to 500.
4.10.1.3 Satellite Connection Test
The Satellite connection test is composed of three tests:
• The Physical layer test, checks if the physical layer of the modem - satellite connection is able to
receive data.
• The Data link layer test, checks if the system is able to send data to the satellite.
• The Network layer test, checks the IP connection.
4.10.1.4 Software Test
The Software test verifies the validity of the software.
