VLAN Overview
The VLAN Overview parameters are set by the Service Provider and cannot be edited
by the end user.
Parameter Description
Layer 3 VLANs
Ports
Indicates the external Ethernet port.
VLAN Tag Indicates a separation between different virtual networks.
Virtual Network Name of the virtual network the modem belongs to.
An MDM22X0 can belong to 4 different networks.
Gateway Address (IPv4) IPv4 address used as gateway address for the connected CPEs
within that network.
Gateway Netmask (IPv4) Network range for the user’s LAN within that network.
Gateway Address (IPv6) IPv6 address used as gateway address for the connected CPEs
within that network.
Gateway Netmask (IPv6) Network range for the user’s LAN within that network.
DHCPv4 enabled Indicates whether the DHCP server on the terminal is enabled or
not.
4.7.1.3 Modify the Ethernet Interface Configuration
» Click on Edit in the Web Interface > View Configuration Ethernet interface to change the
Ethernet Settings.
» Edit the parameters to be changed.
» Click on Save in the Web Interface > Edit Configuration Ethernet interface to save the new
settings.
The Ethernet interface configuration is now saved.
