14/71
Modem Web Interface
MDM2210
User Manual R4.1 v1.0
4.5.2.3 Satellite Overview
The modem state is indicated by a state description. The possible modem state descriptions are
given below.
Modem State
Description
Awaiting
installer action
The terminal is waiting for an action of the installer.
Satellite
network lookup
The terminal is looking for the satellite network.
Synchronizing
The terminal found the satellite network and time synchronization.
Synchronized
The terminal is synchronized and can directly log in on the satellite network
when IP traffic is received via the Ethernet interface.
Network login The terminal is trying to log in on the satellite network.
Operational
The terminal is logged in.
An error message can be displayed. This error message displays the current error status and will be
reset when the terminal has entered the satellite network and the terminal is operational.
Please refer to the Troubleshooting Guide on the CD-ROM (provided with your modem)
for more details on possible errors and actions needed to resolve the occurring error.
The demodulator state is built as follows: see table below for more details.
• -95.0 dBM, Es/No: 23.2 dB, <Satellite network name>
Demodulator
Label Value
Description
-xx.x dBm Indication of the received signal strength expressed in dBm. This
indication can change when going from pointing mode to operational
mode.
Es/No
Es/No is an indication of the received signal quality expressed in dB.
This indication can change when going from pointing mode to
operational mode.
Satellite network
name
Optional satellite network name as specified by the Service Provider.
4.5.2.4 Software version
The running software version is indicated by its version number.
