4.7.3.2 The Parameters of the Satellite Interface
The displayed parameters and their descriptions are shown in the table below.
Parameter Description
General
Active Beam ID Identifier of the beam in which the terminal currently operates.
Beam ID Identifier of the beam whose parameters are displayed in the GUI.
Satellite Properties
Polarization
Skew
Skew angle in degrees applied by the satellite operator. Check with your
satellite operator to know this value.
The value is a positive or negative integer with dotted decimal notation.
Orbital Position Orbital position of the satellite in degrees and East/West selection.
Satellite Latitude
Variance
Only applicable in case of automatic pointing.
Typically used for inclined orbit satellites. Check with your satellite operator
to know this value.
Max Skew Polarization adjustment angle.
TX Polarization Reflects the polarization of the received carrier.
Possible values are:
• Horizontal
• Vertical
• Circular Left
• Circular Right
Extra Hunt
Parameters
Future use
Initial Receive Carrier
Default
Marker for the default Initial Receive Carrier.
Transport Mode
• DVB-S
• DVB-S2 (CCM)
• DVB-S2 (ACM)
Frequency
Initial receive frequency (GHz)
Symbol Rate Initial receive symbol rate (Mbaud)
Polarization
Reflects the polarization of the received carrier. Possible values are:
• Horizontal
• Vertical
• Circular Left
• Circular Right
Pointing Carrier
Default
Marker for the default pointing carrier
