Newtec MDM2210 - Viewing Satellite Interface Configuration

37/71
Modem Web Interface
MDM2210
User Manual R4.1 v1.0
4.7.3.1 View the Satellite Interface Configuration
As already mentioned above, maximum two initial receive carrier settings and pointing carrier
settings can be assigned and displayed. Only the settings that are enabled are displayed. How to
change the satellite interface configuration is described in section
EdittheSatelliteInterfaceConfigurationonpage41.
If two initial receive carriers are enabled and displayed, the preferred initial receive carrier is
marked green.
If two pointing carriers are enabled and displayed, the default pointing carrier is marked green.
The pointing carrier that is used for pointing is selected through the Terminal Installation
menu. Refer to TerminalInstallationonpage16 for more details.
The parameter values in the figure below are just an example. They are randomly
chosen and may therefore differ from the predefined settings on your modem.
If multiple beams are configured, you can select another beam from the dropdown list in the General
section to view its satellite settings. Changing the active beam is done via the Terminal Installation
menu.
