Modem Web Interface
MDM2210
User Manual R4.1 v1.0
Parameter Description
or Voltage settings. If ‘Band selection’ is not used, then only set one RF
Stop frequency (as there is no distinction between high and low band).
High Band L.O. Local oscillator frequency (in GHz) used when the LNB is operating in
high band, which can typically be found in the LNB datasheet.
Only applicable if ‘Band selection’ is used in 22 kHz or Voltage
settings. If ‘Band selection’ is not used, then only set one local oscillator
frequency (as there is no distinction between high and low band).
High Band RF Start Minimum frequency used by the LNB when operating in high band.
Only applicable if ‘Band selection’ is used in 22 kHz or Voltage
settings. If ‘Band selection’ is not used, then only set one RF Start
frequency
(as there is no distinction between high and low band).
High Band RF Stop Maximum frequency used by the LNB when operating in high band.
Only applicable if ‘Band selection’ is used in 22 kHz or Voltage
settings. If ‘Band selection’ is not used, then only set one RF Stop
frequency
(as there is no distinction between high and low band).
Current Min / Max Minimum/maximum allowed current on the RX interface. This input is
required for correct functioning of the current measurement test (see
section HardwareTestonpage59 ).
Transmit
MUC Multiplication
factor
Multiplication factor used by the MUC to convert from IF to RF-band
(as n*transmitted IF freq = transmitted RF freq, where n = multiplication
factor).
MUC RF Start Minimum RF frequency the MUC can transmit.
MUC RF Stop Maximum RF frequency the MUC can transmit.
Current Min / Max Minimum/maximum allowed current on the TX interface. This input is
required for correct functioning of the current measurement test (see
sectionHardwareTestonpage59).
