Installation and System Design Guide 7
Issue Number: 1
This declaration is issued under the sole responsibility of the manufacturer. The object of the declaration is in conformity with the relevant Union
harmonization legislation. The declaration applies to the variable speed drive products shown below:
The model number may be followed by additional characters that do not affect the ratings.
This declaration relates to these products when used as a safety component of a machine. Only the Safe Torque Off function may be used
for a safety function of a machine. None of the other functions of the drive may be used to carry out a safety function.
These products fulfil all the relevant provisions of the Machinery Directive 2006/42/EC and the Electromagnetic Compatibility Directive (2014/30/EU).
EC type examination has been carried out by the following notified body:
TUV Rheinland Industrie Service GmbH
Am Grauen Stein
D-51105 Köln
Germany
Notified body identification number: 0035
The harmonized standards used are shown below:
EC type-examination certificate numbers:
01/205/5270.02/17 dated 2017-08-28
Person authorised to complete the technical file:
P Knight
Conformity Engineer
Newtown, Powys, UK
EU Declaration of Conformity (including 2006 Machinery Directive)
Nidec Control Techniques Ltd
The Gro
Newtown
Powys
UK
SY16 3BE
Model No. Interpretation Nomenclature aaaa - bbc ddddde
aaaa Basic series
M600, M700, M701, M702, M708, M709, M751, M753, M754, F300, H300, E300, HS70, HS71, HS72, M000,
RECT
bb Frame size 01, 02, 03, 04, 05, 06, 07, 08, 09, 10, 11
c Voltage rating 1 = 100 V, 2 = 200 V, 4 = 400 V, 5 = 575 V, 6 = 690 V
ddddd Current rating Example 01000 = 100 A
e Drive format
A = 6P Rectifier + Inverter (internal choke), D = Inverter, E = 6P Rectifier + Inverter (external choke),
T = 12P Rectifier + Inverter (external choke)
EN 61800-5-1:2016 Adjustable speed electrical power drive systems - Part 5-2: Safety requirements - Functional
EN 61800-5-1:2016 (in
extracts)
Adjustable speed electrical power drive systems - Part 5-1: Safety requirements - Electrical, thermal and energy
EN 61800-3: 2004+A1:2012 Adjustable speed electrical power drive systems - Part 3: EMC requirements and specific test methods
EN ISO 13849-1:2015 Safety of Machinery, Safety-related parts of control systems, General principles for design
EN 62061:2005 + AC:2010
+ A1:2013 + A2:2015
Safety of machinery, Functional safety of safety related electrical, electronic and programmable electronic control
systems
IEC 61508 Parts 1 - 7:2010 Functional safety of electrical/ electronic/programmable electronic safety-related systems
