14 - FORM NO. 56043124 - Condor XL
™
MAINTENANCE
MAINTENANCE SCHEDULE
Keep the machine in top condition by following the maintenance schedule closely. Maintenance intervals given are for average operating
conditions. Machines used in severe environments may require service more often. In general:
• Keep the fuel tank filled (gasoline and diesel). This helps to reduce condensation and moisture entering the fuel system.
• Be aware of the red Warning Indicator Light (62), the yellow Attention Indicator Light (66) and the LCD Display (64) on the operator
panel for icons and fault codes that indicate a critical or non-critical fault condition. Note: Refer to the MAIN CONTROL BOARD
WARNING AND ATTENTION INDICATOR LIGHTS section for a listing and explanation of the LCD display icons and fault codes.
• Reference the engine service manual for recommended engine service intervals and procedures.
Recommended Service Materials
• Engine Oil (5W-30)
• Hydraulic Oil (10W-30)
• Manufacturer-recommended Coolant (antifreeze) 50/50 mix
• Lithium-base Grease
• Loctite
®
(or equivalent) thread sealant in the appropriate grades
• Never-Seez
®
(or equivalent) anti-seize compound
Daily Maintenance
Maintenance Item Procedure
Perform “After Use” maintenance steps
“After use” maintenance is normally the responsibility of the machine operator. See “AFTER
USE” maintenance steps in the operator manual.
Check the engine oil level
Check the engine coolant level in the reservoir
Check for engine and coolant leaks
Engine
Check the air cleaner service indicator and service the air filter when the indictor is shown red
Operator panel Check for a hydraulic filter plugged indicator light (66) on the operator panel display (64)
Check the oil level in the hydraulic oil reservoir (level should be to bottom of screen)
Hydraulic system
Check for any hydraulic leaks
Check the cover gasket for damage/wear
Check that the drain hose cap is sealed
Recovery tank
Drain and clean the inside of the tank, flush with clean water
Squeegee pick up tool Clean the tool, check the blades for damage/wear and deflection
Scrub housing side skirts Check for damage/wear on both the main and right side
Scrub brushes, main and right side scrub Check for debris wrapped around the brushes and for damage/wear
Wet debris hopper Clean the hopper, debris screen and hose
Parking brake and foot pedal brake Check for proper operation of brakes, make adjustments as needed
Maintenance Every 15-20 Hours
Maintenance Item Procedure
Check the electrolyte level in the battery
Battery
Check the battery cables and connections
Solution tank filter Inspect and clean the debris filter on the solution filter system
Solution delivery trough Clean the drain holes
AXP detergent system Purge the chemical delivery lines
Scrub deck skid plates Inspect for wear (replace if worn to ǩ inch
Scrub brushes Rotate and flip the main scrub brushes
Dust Guard Clean the dust control system spray nozzles
