90 - FORM NO. 56043124 - Condor XL
Item Description
1 Solution Tank
2 Solution Flow Control Valve
3 Solution Filter
4 Main Solution Pump (M4)
7 Solution Tank Drain Hose
8 Mist Pump (M5)
9 Wand Pump (M8)
10 Mist Spray Nozzles
11 Wash Hose Spray Gun
A = Solution fl ow to the scrub deck see “Solution Flow Diagram –
Standard with Right Front Scrub” for more details.
SOLUTION FLOW DIAGRAM - ACCESSORIES
APPENDIX
To Next Page
