32 - FORM NO. 56043124 - Condor XL
™
ELECTRICAL SYSTEM
ENGINE ELECTRICAL COMPONENT LOCATIONS – GM 1.6 GASOLINE
O
2
Sensor (in exhaust manifold)
(pre CATCON)
TMAP Sensor ETC (Electronic Throttle Control)
ECT (Engine Coolant Temperature)
Sensor
Fuel Injectors and Connectors
Fuel Pump and Manifold
(mounted on fuel tank)
ECM and Oil Pressure Switch Crank Position Sensor
To Next Page
