FORM NO. 56043124 - Condor XL - 89
Item Description
1 Solution Tank
2 Solution Flow Control Valve
3 Solution Filter
4 Main Solution Pump (M4)
5 Main Solution Valve (L10)
6 *Right Solution Valve (L11)
7 Solution Tank Drain Hose
* = Only if equipped with Right Front Scrub.
APPENDIX
SOLUTION FLOW DIAGRAM - STANDARD WITH RIGHT FRONT SCRUB
