TECHNICAL SPECIFICATIONS
Power System Performance
Engine
See the ENGINE SYSTEM/ENGINE SPECIFICATIONS
section
Engine speeds
4-cylinder 1.6L GM (gasoline and LP)
Idle - 1200 RPM
Normal Run - 2200 RPM
High Output Turbo - 2400 RPM
4-cylinder 1505 Kubota Diesel
Idle - 1300 RPM
Normal Run - 2200 RPM
High Output Turbo - 2400 RPM
Transport speed forward 8 mph (12.8 kph)
Transport speed reverse 3 mph (4.8 kph)
Grade ability – Cleaning 6° / 10.5% - all models
Grade ability – Transporting 9° / 16% - all models
Hydraulic
Hydraulic reservoir 10 gal. (37.8 L), fl uid type: 10W-30 engine oil
Hydraulic system components See hydraulic manual section
Steering Brakes and Tires
Steering Front wheel, hydraulic cylinder and rotary valve controlled
Brakes (service)
Mechanical drum brakes, one on each rear wheel, cable
actuated
Tire (front 1) drive/steer Size 18 in x 6 in (457 mm x 152 mm) P7 solid
Tire (rear 2) load bearing Size 16 in x 4 in (406 mm x 101 mm) solid
Solution and Chemical System Delivery Rates
Solution system fl ow rates (fi ve settings)
Setting 1 – 1.6 gal/min (6 L/min)
Setting 2 – 1.9 gal/min (7.2 L/min)
Setting 3 – 2.3 gal/min (8.7 L/min)
Setting 4 – 2.7 gal/min (10.2 L/min)
Setting 5 – 3.1 gal/min (11.7L/min)
AXP detergent dispensing system
Refi llable cartridge, Qty (2) 2.5 gal (9.5L)
Available dilution rates: 300:1, 256:1, 200:1, 150:1, 128:1,
100:1, 64:1, 50:1, 32:1, 26:1
Extended Scrub System
Dust Guard system (side broom dust control )
Standard nozzle size .015” dia. Flow volume – .033 gal/min
(0.125 L/min) @ 40 psi.
Optional nozzle size .026 Dia. Flow volume – .1 gal/min
(.379 L/min) @ 40 psi.
