20 - FORM NO. 56043124 - Condor XL
Copyright 2009 Nilfisk-Advance Page 1 of 2 6/29/2009
Advance Condor XL 48/60/62/67 G/P/D
PM Checklist
Defect Codes
Customer A needs adjustment
B binding
Address C dirty or contaminated
D damaged, bent or torn
City St Zip L leaks
M missing
Model Serial Hours W worn out
Ref
OPERATIONAL INSPECTION ITEMS
OK
Defect Codes
(circle)
Does
Not
Work
1 Check drive pedal sensor operation (to test depress drive pedal and start the engine, it
should not start.)
A B C
2 Engine starting with pedal in neutral (if it will not start check pedal calibration
programming)
A
3 Engine idle speed, GM/1200 RPM & Kubota/1300 RPM A rough
4 Normal operational speed (run switch setting) 2200 RPM A low power
Turbo high speed (hold 2200 RPM switch setting for 2 sec. to enter ) 2400 RPM
5 Drive pedal linkage (check for FWD/REV drive and any neutral creep) A B
6 Drive system performance (max Fwd 8 mph) Noisy sluggish
7 Brakes (check both service & parking)
A B W
8 Steering excessive play
9 Right side scrub brush raise/lower (model option if equipped) B D L
10 Right side scrub brush on/off (must have main scrub turned on) B L
11 Side sweep broom(s) raise/lower (model option if equipped) A B
12 Side broom(s) on/off B L
13 Dust guard (sweep dust control) On/Off (model option if equipped)
A C L
14 Scrub system (Raise/Lower and auto scrubbing functions) <----->
15 Main scrub brushes On/Off (will drift) <----->
16 Scrub Brush (pressure settings 1,2 &3) A B
17 Solution control (On/Off and flow volume min/max) C D
18 Test & purge the detergent AXP system (model option if equipped)
C L W
19 Squeegee system (raise/lower and auto lift in reverse) <----->
20 Vacuum Performance (Sealed water lift 34" @ 2200 RPM) C L
21 Headlights, gauges and (optional) accessories rotating beacon, backup alarm <----->
22 Tilt steering mechanism and seat adjustment lever <----->
23
Ref
VISUAL INSPECTION ITEMS
Comments
OK
Defect Codes
(circle)
Does
Not
Work
24 Side sweep broom(s) bristles min wear 3 inches A B D W
25 Side broom motor(s) B L
26 Scrub brush motor(s) Also RT scrub brush B L
27 Main scrub brushes, check for wear and rotate (1.75” length) Min wear .875 D W
28 Scrub deck housing & door skirts
C D W
29 Solution system pumps and solenoid valves as many as 4 pumps
C L W
30 Solution tank, delivery hoses & filter clean filter screen
C L M
31 Vacuum impellor motor & hose C L D
32 Recovery tank screen & float clean screen
B C
33 Recovery tank cover gasket
D L W
34 Recovery tank drain hose & cap C D L M
35 Squeegee pick-up hose back flush C L
