FORM NO. 56043124 - Condor XL
™
- 21
Copyright 2009 Nilfisk-Advance Page 2 of 2 6/29/2009
Ref
VISUAL INSPECTION ITEMS (continued)
Comments
OK
Defect Codes
(circle)
Does
Not
Work
36 Squeegee tool & blades clean & rotate
C D W
37 Squeegee casters, leveler adjustment knob & linkage grease C W
38 Hydraulic lift cylinders (squeegee, RT side & main scrub
deck)
B L
39 Battery clean & water C
40 Engine, oil level, hoses & belts C D L
41 Engine air cleaner element (inner & outer) check SVR indicator C L
42 Engine coolant level fill at reservoir C L
43 Radiator & oil cooler core blockage clean
C D L
44 Hydraulic oil reservoir level (10W-30 engine oil only) to bottom of screen C L
45 Hydraulic system hoses & fittings L
46 Propulsion (drive) pump dump valve (tow valve) B D
47 Propulsion drive & accessory pump L
48 Propulsion pump hydro back cable & clevis connections A B D
49 Propulsion pump hydraulic filter C L
50 Gasoline/Diesel fuel tank , filter & lines Xx hours
C L W
51 LP tank, hoses & fittings L W
52 LP fuel filter SVR life 1500 Hrs C
53 LP fuel regulator, lock off valve & hoses L
54 Diesel glow plug function light hard starting <----->
55 Gasoline & Diesel fuel tank strainer yearly C
56 Brake cable and parking brake pedal A B
57 Circuit breaker panel
D M W
58 Front tire (check lug nut torque 100 FT LB, 135Nm)
A
59 Front drive wheel motor, steer spindle, rack & cylinder grease pinion & rack
D L W
60 Front & rear tires tread wear C W
61 Scrub housing debris hopper (tray) clean C
62 Scrub housing recovery hose & pick-up screen back flush/clean C
63 Dust guard spray nozzles & strainers clean C L W
64
65
66
67
68
69
70
71
NOTE: For additional service information see service manual form number 56043124 and
operators manual form number 56041705.
Defect Codes A needs adjustment C dirty or contaminated M missing
B binding D damaged, bent or torn W worn out
L leaks
WORK COMPLETED BY: ACKNOWLEDGED BY:
Service Technician Signature Date Customer Signature Date
