24 - FORM NO. 56043124 - Condor XL
KNOW YOUR MACHINE
CONTROL PANEL
50 Key Switch
51 Engine Speed Switch
52 Dust Guard
53 Side Broom/Scrub ON / OFF Switch
53a Side Broom DOWN adjust Switch
53b Side Broom UP adjust Switch
54 Scrub ON / Scrub Mode Select
55 Scrub OFF
56 Solution Switch
56a Solution Flow Decrease Switch
56b Solution Flow Increase Switch
57 Vacuum Switch
58 Wand Switch (optional)
59 Horn Switch
60 Extended Scrub Switch (optional)
61 Detergent System (AXP models only)
62 Warning Indicator Light (RED) (see page 25)
63 Left Turn Signal (optional)
64 Display
64a Scrub Pressure Indicator
64b Hour Meter
64c AXP Indicator (optional)
64d Fuel Gauge
64e Solution Flow Indicator
64f Extended Scrub Indicator (optional)
65 Right Turn Signal (optional)
66 Attention Indicator Light (YELLOW) (see page 26)
67 Emergency Flashers (optional)
68 Headlights
(scrub 1) (scrub 2) (scrub 3)
press 1 time press 2 times press 3 times
Flow Flow Flow
Rate 1 Rate 2 Rate 3
(scrub 1) (scrub 2) (scrub 3)
press 1 time press 2 times press 3 times
