FORM NO. 56043124 - Condor XL
™
- 65
CONTROL LOCKS
LIGHTS
BACK-UP ALARM
RECOVERY SYSTEM
VACUUM OFF DELAY
SQUEEGEE UP DELAY
ENGINE IDLE DELAY
EXTENDED SCRUB SYSTEM
USE ANYTIME, USE CLEAN FIRST
10 SECOND S (10-30 SEC, INCREMENT=1 SEC)
15 SECOND S (5-30 SEC, INCREMENT=1 SEC)
START UP STAT E
OFF, ON, LAST STATE
OPERAT ING MODE
SOLUTION IN REVERSE
OFF,ON
20 SECOND S (10-250 SEC, INCREMENT = 1 SEC)
UNLOCK, DETERGENT, DETERGENT & SOLUTION
NORMAL,ALWAYSON
OFF, REVERSE,FORWARD&REVERSE
SIDE SCRUB SYSTEM
START UP STAT E
OFF, ON, LAST STATE
SIDE SWEEP SYSTEM
BROOM START UP
OFF, ON, LAST STATE
DUST GUARD START UP
OFF, ON, LAST STATE
TIMEOUT MODE
NORMAL, IN NEUTRA L
SOLUTION_IN_REVERSE_FLG: 0=OFF(false),1=ON(true)
SQUEEGEE_OFF_DELAY: 50-300, default = 150
VACUUM_OFF_DELAY: 100-300, default = 100
RECOVERY_TIMEOUT_MODE: 0=normal, 1 = in neutral
CONTROL_LOCK: 0=unlock
, 1 = detergent mix only, 2 = detergent mix and solution flow
Only appears when SIDE_SCRUB_INSTALLED_FLG = 1 (from configuration menu)
SIDE_SCRUB_START_MODE: 0 = o ff, 1 = on, 2=laststate
Only appears when SIDE_SWEEP_INSTALLED_FLG = 1 (from configuration menu)
SIDE_SWEEP_START_MODE: 0 = off, 1 = on, 2 = last state
SIDE_MIST_START_MODE: 0 = off, 1 = on, 2 = last state
Only appears when RECYCLE_INSTALLED_FLG = 1 (from configuration menu)
RECYCLE_START_MODE: 0 = off, 1 = on, 2=laststate
RECYCLE_OP_MODE: 0 = u se anytime, 1=usecleanfirst
IDLE_TIME_OUT: 100-2500, default = 200
Only appears when BACKUP_ALARM_INSTALLED_FLG = 1 (from configuration menu)
BACKUP_ALARM_OP_MODE: 0 = off, 1= reverse only
, 2 = forward and reverse
LIGHTS_OP_MODE: 0 = normal
,1=alwayson
Entered by pressing and holding SCRUB OFF and SCRUB ON buttons during
3 second power on sequence.
USER OPTIONS MENU (continued)
To Next Page
