ELECTRICAL SYSTEM
CONTROL BOARD PROGRAMMING OPTIONS
Confi guration Menu
1 Press and hold the Emergency Flashers (67) and Headlight (68) switches.
2 Turn the ignition Key Switch (50) to the run (on) position.
3 Continue to hold the Emergency Flashers and Headlight switches until all the display panel lights turn off (approximately three seconds), then
release the switches. The fi rst line of the LCD display will read “CONFIGURATION MENU”.
4 Press the Side Broom Up (53b) and Side Broom Down (53a) switches to scroll through the confi guration menu items as shown in the chart
below.
5 When the arrow is pointing to the desired menu item, press the green Scrub On switch (54) to display the next level of confi guration options.
6 Press the Side Broom Up (53b) and Side Broom Down (53a) switches to select the desired option.
7 When the arrow is pointing to the confi guration option:
 Press the green Scrub On switch (54) to select the option. The display will then return to the previous menu level.
 Press the red Scrub Off switch (55) to return to the previous menu level without selecting the option.
8 To save the new setting(s), turn the ignition Key Switch to the off position. The new setting(s) will be saved and remain in effect until changed
again.
ENGINE TYPE
CONFIGURATION MENU
UNDEFINED , PROPANE, GASOLINE, DIESEL
SIDE SCRUB SYSTEM
NOT INSTALLED, INSTA LLED
SIDE SWEEP SYSTEM
NOT INSTALLED, INSTA LLED
EXTENDED SCRUB SYSTEM
NOT INSTALLED, INSTA LLED
BACK-UP AL ARM
NOT INSTALLED, INSTA LLED
LIGHTS
NOT INSTALLED, INSTA LLED
DETERGENT SYSTEM
NOT INSTALLED,INSTALLED
INSTALLED ?
DISPLAY FORMAT
RATIO, PERCENTAGE
RESTORE DEFAULTS
ARE YOU SURE ?
Entered by pressing and holding HAZARD and LIGHT but-
tons during 3 second power on sequence.
ENGINE_TYPE: 0 = undefined
, 1 = propane, 2 = gasoline, 3 = diesel
CHEMICAL_SYSTEM_INSTALLED_ FLG: 0 = not installed
, 1 = installed
CHEMICAL_DISPLAY_TYPE: 0=ratio
, 1 = percentage
SIDE_SCRUB_INSTALLED_FLG: 0 = not installed
, 1 = installed
SIDE_SWEEP_INSTALLED_FLG: 0 = not installed
,1=installed
RECYCLE_INSTALLED_FLG: 0 = not installed
, 1 = installed
BACKUP_ALARM_INSTALLED_FLG: 0 = not installed
, 1 = installed
Refers to all lights EXCEPT headlights. Headlights are standard on all models.
LIGHTS_INSTALLED_FLG: 0 = not installed
, 1 = installed
Restores all configuration and option values to their factory default state.
