FORM NO. 56043124 - Condor XL
™
- 71
ENGINE DIAGNOSTICS
1.6L DTC CODE TO SPN:FMI CODE CROSS REFERENCE
DTC
Code
Description
SPN
Code
FMI
Code
DTC
Code
Description
SPN
Code
FMI
Code
16 Crank Never Synced at Start 636 8 604 RAM Failure 630 12
91 Fuel Pump Low Voltage 94 4 606 COP Failure 629 31
92 Fuel Pump High Voltage 94 3 642 External 5V Reference Low 1079 4
107 MAP Low Voltage 106 4 643 External 5V Reference High 1079 3
108 MAP High Pressure 106 16 685 Power Relay Open 1485 5
111 IAT Higher Than Expected 1 105 15 686 Power Relay Shorted 1485 4
112 IAT Low Voltage 105 4 687 Power Relay Short to Power 1485 3
113 IAT High Voltage 105 3 1111 Fuel Rev Limit 515 16
116 ECT Higher Than Expected 1 110 15 1112 Spark Rev Limit 515 0
117 ECT Low Voltage 110 4 1151 Closed Loop Multiplier High LPG 520206 0
118 ECT High Voltage 110 3 1152 Closed Loop Multiplier Low LPG 520206 1
121 TPS 1 Lower Than TPS 2 51 1 1155 Closed Loop Multiplier High Gasoline 520204 0
122 TPS 1 Signal Voltage Low 51 4 1156 Closed Loop Multiplier Low Gasoline 520204 1
123 TPS 1 Signal Voltage High 51 3 1161 Adaptive Learn High LPG 520202 0
127 IAT Higher Than Expected 2 105 0 1162 Adaptive Learn Low LPG 520202 1
129 BP Low Pressure 108 1 1165 LPG Cat Monitor 520213 10
134 EGO 1 Open/Inactive 724 10 1171 LPG Pressure Higher Than Expected 520260 0
154 EGO 2 Open/Inactive 520208 10 1172 LPG Pressure Lower Than Expected 520260 1
171 Adaptive Learn High Gasoline 520200 0 1173 EPR Comm Lost 520260 31
172 Adaptive Learn Low Gasoline 520200 1 1174 EPR Voltage Supply High 520260 3
182 Fuel Temp Gasoline Low Voltage 174 4 1175 EPR Voltage Supply Low 520260 4
183 Fuel Temp Gasoline High Voltage 174 3 1176 EPR Internal Actuator Fault 520260 12
187 Fuel Temp LPG Low Voltage 520240 4 1177 EPR Internal Circuitry Fault 520260 12
188 Fuel Temp LPG High Voltage 520240 3 1178 EPR Internal Comm Fault 520260 12
217 ECT Higher Than Expected 2 110 0 1612 RTI 1 Loss 629 31
219 Max Govern Speed Override 515 15 1613 RTI 2 Loss 629 31
221 TPS 2 Signal Voltage Low 51 0 1614 RTI 3 Loss 629 31
222 TPS 2 Signal Low Voltage 520251 4 1615 A/D Loss 629 31
223 TPS 2 Signal High Voltage 520251 3 1616 Invalid Interrupt 629 31
336 Crank Sync Noise 636 2 1626 CAN Tx Failure 639 12
337 Crank Loss 636 4 1627 CAN Rx Failure 639 12
420 Gasoline Cat Monitor 520211 10 1628 CAN Address Confl ict Failure 639 13
524 Oil Pressure Low 100 1 2111 Unable to Reach Lower TPS 51 7
562 System Voltage Low 168 17 2112 Unable to Reach Higher TPS 51 7
563 System Voltage High 168 15 2229 BP Pressure High 108 0
601 Flash Checksum Invalid 628 13
