88 - FORM NO. 56043124 - Condor XL
™
sort
recovery system
scrub system
solution system
chemical system
side scrub system
side sweep system
side mist system
recycle system
critical fault
non-critical fault
control board fault
other fault
System Fault Name
Fault Code
Inputs (logic ORed unless specified) [Name used in flow charts]
Inputs [Name used in program code] Comments
x
x
x
x
x
RECOVERY_SYSTEM_FAULT_FLG set if any of the following are set
x
x
09 VACUUM_FAULT_FLG FAULT_VACUUM_MOTOR_SOLENOID
x
x
11 SQUEEGEE_UP_FAULT_FLG FAULT_SQUEEGEE_UP_SOLENOID
x
x
12 SQUEEGEE_DOWN_FAULT_FLG FAULT_SQUEEGEE_DOWN_SOLENOID
x
x
x
x
SCRUB_SYSTEM_FAULT_FLG set if any of the following are set
x
x
13 SCRUB_MOTOR_FAULT_FLG FAULT_SCRUB_BRUSH_SOLENOID
x
x
15 SCRUB_LOCK_FAULT_FLG FAULT_SCRUB_CYLINDER_LOCK_SOLENOID
x x 01 SCRUB_PRESSURE_FAULT_FLG FAULT_SCRUB_PRESSURE
up and down pressure valves on same fault line
x
x
x
SOLUTION_SYSTEM_FAULT_FLG set if any of the following are set
x x 00 SOLUTION_PUMP_FAULT_FLG FAULT_SOLUTION_PUMP
same fault line used for clean and recycle
p
um
p
s
x
x
07 SOLUTION_VALVE_FAULT_FLG FAULT_MAIN_SOLUTION_SOLENOI
D
x
x
CHEMICAL_SYSTEM_FAULT_FLG set if any of the following are set
x
x
31 CHEMICAL_PUMP1_FAULT_FLG
x
x
32 CHEMICAL_PUMP2_FAULT_FLG
x
x
SIDE_SCRUB_SYSTEM_FAULT_FLG set if any of the following are set
x
x
18 SIDE_SCRUB_LIFT_FAULT_FLG FAULT_SIDE_SCRUB_LIFT_SOLENOID
x
x
16 SIDE_CLEAN_MOTOR_FAULT_FLG FAULT_SIDE_SWEEP_SCRUB_SOLENOID
x
x
08 SIDE_SOLUTION_FAULT_FLG FAULT_SIDE_SCRUB_SOLUTION_SOLENOID
x
x
SIDE_SWEEP_SYSTEM_FAULT_FLG set if any of the following are set
x
x
30 SIDE_SWEEP_LIFT_FAULT_FLG FAULT_ACTUATOR
x
x
16 SIDE_CLEAN_MOTOR_FAULT_FLG FAULT_SIDE_SWEEP_SCRUB_SOLENOID
x
x
SIDE_MIST_SYSTEM_FAULT_FLG set if any of the following are set
x
x
04 SIDE_MIST_PUMP_FAULT_FLG FAULT_SIDE_SWEEP_MIST_PUMP
x
x
RECYCLE_SYSTEM_FAULT_FLG set if any of the following are set
x x 00 SOLUTION_PUMP_FAULT_FLG FAULT_SOLUTION_PUMP
same fault line used for clean and recycle
p
um
p
s
x
ENGINE_SPEED_FAULT_FLG set if any of the following are set
x
x
05 2200RPM_OUT_FAULT_FLG FAULT_ECM_2200
x
x
06 2400RPM_OUT_FAULT_FLG FAULT_ECM_2400
x
x
10 RECYCLE_SOLUTION_VALVE_FAULT_FL
G
FAULT_RECYCLE_SOLUTION_SOLENOID not used
x
x
03 SPRAY_HOSE_FAULT_FLG FAULT_WAND_SOLUTION_PUMP
x
x
19 HORN_FAULT_FLG FAULT_HORN
x
x
17 BACKUP_ALARM_FAULT_FLG FAULT_BACKUP_ALARM
x
x
x
x
x
x
x
x
x
x
02 MAIN_RELAY_FAULT_FLG FAULT_MAIN_POWER_RELAY inhibits ALL functions
x
x
25 VACC1_FAULT_FLG FAULT_VACC1
x
x
26 VACC2_FAULT_FLG FAULT_VACC2
x
x
27 VACC3_FAULT_FLG FAULT_VACC3
x
x
28 VACC4_FAULT_FLG FAULT_VACC4
x
x
29 VACC5_FAULT_FLG FAULT_VACC5
x
x
20 LEFT_TURN_FAULT_FLG FAULT_LEFT_TURN_LAMP
x
x
21 RIGHT_TURN_FAULT_FLG FAULT_RIGHT_TURN_LAMP
x
x
23 LEFT_STOP_FAULT_FLG FAULT_LEFT_STOP_LAMP
x
x
24 RIGHT_STOP_FAULT_FLG FAULT_RIGHT_STOP_LAMP
x
x
22 HEAD_TAIL_LAMP_FAULT_FLG FAULT_HEAD_LAMPS
x
14 GLOW_PLUG_OUT_FAULT_FLG FAULT_GLOW_PLUG_RELAY diesel model only
x
x
35 LOW_VOLTAGE_FAULT_FLG low voltage when engine is running
xxxxxxxx x x 37 LOW_OIL_PRESSURE_FLG
diesel only - causes ENGINE_FAULT_FLG to be set
xxxxxxxx x x 33 ENGINE_HOT_FLG
coolant temperature high - causes ENGINE_FAULT_FLG to be set on diesel machines
xxxxxxxx x x 38 ENGINE_FAULT_FLG
occurs if engine temp too high (diesel), oil pressure low (diesel), or if engine run has changed to false and key is on (gas &
p
ro
p
ane
)
.
x x 36 SERVICE_ENGINE_FLG
set when ECM activates MIL output - could be for man
y
different reasons
x 34 HYDRAULIC_TEMP_FAULT_FLG
Set if hydraulic temperature exceeds 220°F for 15 seconds
x 39 HYDRAULIC_FILTER_FAULT_FLG
Set if hydraulic temperature greater than or equal to 100°F AND hydraulic filter input is active.
Inhibits:
APPENDIX
FAULTS
