FORM NO. 56043124 - Condor XL
™
- 79
HYDRAULIC SYSTEM
GENERAL HYDRAULIC SPECIFICATIONS TABLE
Accessory Pump 1 Circuits
Displacement
Cu. In.
GPM
RPM
IN
RPM
OUT
PSI
Relief
PSI
Accessory pump 1, engine @ 2200 RPM no systems running (test
port TP1)
.58 5.52 2200 * 120 2700
Vacuum Fan motor (open fan) .129 5.52 8600 2040 2700
Vacuum water lift sealed @ 2200 RPM, 33.7 in/H
2
O
Accessory Pump 2a Circuits
Displacement
Cu. In.
GPM
RPM
IN
RPM
OUT
PSI
Relief
PSI
Accessory Pump 2a non-priority branch, engine @ 2200 RPM, no
systems running (test port TP2)
1.20 8.42 2200 *370 2700
Main scrub brush motors (only) setting (A) no load broom off floor and
** scrub setting #3 pressure
4.5 2200
415
400
A 850
1700**
Main scrub and RT side scrub motors #3 pressure 2200 1880
Right side brush motor speed 11.3 160
Main scrub and dual sweep 2200 1780
Side sweep broom motor speed 17.9 100
Main scrub, RT scrub and LT sweep 2200 1950
Squeegee cylinder 1.50 x 5.00 2200 315
Accessory Pump 2b Circuits
Displacement
Cu. In.
GPM
RPM
IN
RPM
OUT
PSI
Relief
PSI
Accessory Pump 2b priority branch, engine @ 2200 RPM no systems
running (test port TP3)
1.20 3.0 2200 * 296 1500
Steering unit (driving and turning) 4.5 500
Test
Port
Pressure
Type
Controlled
by
Pressure
Setting
PSI
1 750 - 774
2 750 - 767
TP4
Lift
Pressure
Proportioning
Valve S7
3 745 - 779
1 333 - 346
2 393 - 412
Scrub lift cylinder 1.50 x 5.00, engine at 2200 RPM
TP5
Down
Pressure
Proportioning
Relief Valve
S5
3 458 - 499
Propulsion Pump Circuits
Displacement
Cu. In.
GPM
RPM
IN
RPM
OUT
PSI
Relief
PSI
Hydrostat pump charge pressure 250
Hydrostatic pump 1.44 13.7 2200
Forward drive wheel motor speed test @ 8 mph level ground, smooth
concrete, no accessory systems running, foot at full speed forward,
set 153 RPM @ 2400 RPM
18.3
FWD
153
1060@
2200
RPM
1200@
2400
RPM
F
3500
Reverse same as above @ 4 mph, set 78 RPM @2400 RPM
REV
78
R
2500
Hydraulic Reservoir Capacity
Hydraulic reservoir capacity: 10 gallons Oil Type: 10W-30
* The bypass pressure is the pressure reading with no motor or cylinder operating (flow through).
** Scrub brush system hydraulic pressure under load setting #3
To Next Page
