FORM NO. 56043124 - Condor XL
™
- 85
Pin ID
* = no connec-
tion on Rev C
Board
Designa-
tion
Pin As-
signment
Signal Char-
acteristic
Nominal
Voltage at
Connec-
tor (when
activated)
Refer-
ence
To:
Load Or Sup-
ply Charac-
teristics
Comments
J1-27 Input
Recovery
Full Switch
Digital Volt-
age
0V B-
Switch to
Ground
Level switch, ground or open,
opens when tank is full
J1-30 Input
Engine
Coolant
Temp
Analog Volt-
age
0.34-2.93 B-
Engine Control
Module Low
Side Output
J1-31 Input
Throttle
Position
Sensor
Analog Volt-
age
0-5V B-
Pedal Position
Potentiometer
Wiper 5K ohm
Drive Pedal sensor wiper (0-5K
ohm)
J1-32 Input
Hydrau-
lic Filter
Switch
Digital Volt-
age
0V B-
Switch to
Ground
Ground or open, closed when
fi lter plugged
J1-33 Input
Extend
Scrub Lvl
Switch
Digital Volt-
age
0V B-
Switch to
Ground
Ground or open, closed when
tank is empty
J1-34 Output
Ignition
Inhibit
Low Side
Driver
0V B-
MOSFET Gate
On Relay
PCB Assy. - 3
Ma@12V
Ground or fl oat
J2-1 Output
Main Power
Relay
Low Side
Driver
0V B-
Relay Coil -
0.29A@12V
46 ± 5 ohms
J2-2 Output
Side
Sweep/
Scrub
Solenoid
Low Side
Driver
0V B-
Hydraulic Coil
- 1.5A@12V
8 ohms @ 20°C
J2-3 Output
Side Scrub
Lift Sole-
noid
Low Side
Driver
0V B-
Hydraulic Coil
- 1.5A@12V
8 ohms @ 20°C
J2-4 Output
Scrub Lock
Solenoid
Low Side
Driver
0V B-
Hydraulic Coil
- 1.5A@12V
8 ohms @ 20°C
J2-5 Output
Squeegee
Down
Solenoid
Low Side
Driver
0V B-
Hydraulic Coil
- 1.5A@12V
8 ohms @ 20°C
J2-6 Output
Squeegee
Up Sole-
noid
Low Side
Driver
0V B-
Hydraulic Coil
- 1.5A@12V
8 ohms @ 20°C
J2-7 Output
Scrub
Brush
Solenoid
Low Side
Driver
0V B-
Hydraulic Coil
- 1.5A@12V
8 ohms @ 20°C
J2-8
Vacuum
Motor
Solenoid
Low Side
Driver
0V B-
Hydraulic Coil
- 1.5A@12V
8 ohms @ 20°C
J2-10
Side Scrub
Solution
Solenoid
Low Side
Driver
0V B-
Solution
Solenoid -
1.0A@12V
11W
J2-11 Output
Backup
Audible
Alarm
Low Side
Driver
0V B-
Elec-
tronic Alarm
0.25A@12V
To Next Page
