System Management
548
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
© 2021 Nokia.
Use subject to Terms available at: www.nokia.com
3HE 17358 AAAB TQZZA
Parameters num-resources — Specifies the number of resources. Specifying the def keyword
specifies the default number of resources.
Values 0 to 2, def
Default 0
eth-cfm
Syntax eth-cfm num-resources
no eth-cfm
Context configure>system>resource-profile>ingress-internal-tcam
Platforms Supported on all 7210 SAS platforms as described in this document, including platforms
configured in the access-uplink operating mode
Description This command allocates resources for CFM Up MEPs, CFM Down MEPs, ingress MIPs, and
bidirectional MIPs (ingress and egress MIPs).
The no form of this command specifies that the software does not allocate any resources for
use by CFM UP MEPs, and it will allocate the default amount of resources for CFM Down
MEPs.
Parameters num-resources — Specifies the maximum number of resources available for use by
ETH-CFM.
Values Table 58 lists the parameter values.
Note: On most 7210 SAS platforms, ingress MIPs and bidirectional MIP resources are
allocated from the Down MEP and Up MEP resource pool. See the down-mep and up-mep
commands for more information.
Table 58 Number of Resources Available for ETH-CFM
Platforms Min value
(per node)
Max value
(per node)
Default
7210 SAS-M (per node) 0 1 0
7210 SAS-T Access-Uplink mode (per node) 0 1 0
7210 SAS-T Network mode (per node) 0 1 0
7210 SAS-R6 (per IMMv1) 1 3 1
7210 SAS-R6 and 7210 SAS-R12 (per
IMMv2)
131
