Graphing switch chassis data 33
Graph Chassis dialog - SNMP tab
2
The following table describes the fields on this tab.
SNMP tab fields
Field Description
InPkts The total number of messages delivered to the
SNMP from the transport service.
OutPkts The total number of SNMP messages passed
from the SNMP protocol to the transport
service.
InTotalReqVars The total number of MIB objects retrieved
successfully by the SNMP protocol as the
result of receiving valid SNMP Get-Request
and Get-Next PDUs.
InTotalSetVars The total number of MIB objects altered
successfully by the SNMP protocol as the
result of receiving valid SNMP Set-Request
PDUs.
InGetRequests The total number of SNMP Get-Request PDUs
that have been accepted and processed by the
SNMP protocol.
InGetNexts The total number of SNMP Get-Next PDUs
accepted and processed by the SNMP
protocol.
Nortel Ethernet Routing Switch 5500 Series
Configuration - System Monitor ing
NN47200-505 03.01 Standard
5.1 27 August 2007
