56 Chapter 1 General System Monitoring Considerations
EAPOL Stats tab fields
Field Description
EapolFramesRx The number of valid EAPOL frames of
any type that have been received by this
authenticator.
EapolFramesTx The number of EAPOL frame types of any
type that have been transmitted by this
authenticator.
EapolStartFramesRx The number of EAPOL start frames that
have been received by this authenticator.
EapolLogoffFramesRx The number of EAPOL Logoff frames that
have been received by this authenticator.
EapolRespIdFramesRx The number of EAPOL Resp/Id frames that
have been received by this authenticator.
EapolRespFramesRx The number of valid EAP Response frames
(other than Resp/Id frames) that have been
received by this authenticator.
EapolReqIdFramesTx The number of EAPOL Req/Id frames that
have been transmitted by this authenticator.
EapolReqFramesTx The number of EAP Req/Id frames
(Other than Rq/Id frames) that have been
transmitted by this authenticator.
InvalidEapolFramesRx The number of EAPOL frames that have
been received by this authenticator in
which the frame type is not recognized.
EapLengthErrorFramesRx The number of EAPOL frames that have
been received by this authenticator in
which the packet body length field is not
valid.
—End—
EAPOL Diag tab
The EAPOL Diag tab displays read-only EAPOL diagnostic statistics.
To open the EAPOL Diag tab, follow this procedure:
Step Action
1
Open the Graph Port screen by selecting one or multiple ports on
the Device View and then selecting Graph > Por t from the menu.
The Graph Port screen opens.
Nortel Ethernet Routing Switch 5500 Series
Configuration - System Monitor ing
NN47200-505 03.01 Standard
5.1 27 August 2007
Copyright © 2005 - 2007, Nortel Networks
.
