Diagnostic information in the Web-based Management Interface 85
Field Description
Late Collisions The number of times a collision is detected
on a particular interface later than 512
bit-times into the transmission of a packet.
Excessive Collisions The number of frames for which
transmission on a particular interface fails
due to excessive collisions.
—End—
Click Update to refresh the statistical information.
Viewing transparent bridging statistics
To view transparent bridging statistics, follow this procedure:
Step Action
1
Open the Transparent Bridging screen by selecting Statistics >
Transparent Bridging from the menu. This screen is illustrated
below.
Nortel Ethernet Routing Switch 5500 Series
Configuration - System Monitor ing
NN47200-505 03.01 Standard
5.1 27 August 2007
Copyright © 2005 - 2007, Nortel Networks
.
