Diagnostic information in the CLI 75
4
Go to NNCLI via serial interface.
5
Enable action mode.
enable
6
Run the external loopback test.
stack loopback-test external
7
Check the results of the command. "stack loopback-test external
output" (page 75) shows the output from a pass and from a failure.
stack loopback-test external output
Pass Fail
External loopback test PASSED. External loopback test FAILED. Your stack cable
might be damaged.
—End—
Stack monitor
The Stack Monitor uses a set of control values to enable its operation, to
set the expected stack size, and to control the frequency of trap sending.
The stack monitor, if enabled, detects problems with the units in the stack
and sends a trap.
The stack monitor sends a trap for the following events.
•
The number of units in stack changes.
•
The trap sending timer expires.
Each time the number of units in a stack changes, the trap sending timer
resets and the stack monitor compares the current number of stack units
with the configured number of stack units. If it is not equal, the switch sends
a trap and logs a message to syslog. The stack monitor sends traps from
a standalone unit or the base unit of the stack.
When the trap sending timer reaches the configured number of seconds at
which traps are sent, the switch sends a trap and logs a message to syslog
and restarts the trap sending timer. The syslog message is not repeated
unless the stack configuration changes. This prevents the log being filled
with stack configuration messages.
When you enable the stack monitor on a stack, the stack monitor captures
current stack size and uses it as the expected stack size. You can choose a
different value and set it after enabling the feature.
Nortel Ethernet Routing Switch 5500 Series
Configuration - System Monitor ing
NN47200-505 03.01 Standard
5.1 27 August 2007
Copyright © 2005 - 2007, Nortel Networks
.
