Program Change – Level Two
While the control panel is normal with no active alarms, troubles or supervisories, the screen shown
below will be displayed:
To access the programming mode, the
ENTER
key must be pressed, causing the following screen to be
displayed:
Pressing 1 will cause the following screen to appear:
Enter the Level 2 password (default = 11111) then press the
ENTER
key to access Programming Change
Level 2. The screen shown below will appear:
From this screen, the available function choices include Point Disable, Clear History, Walktest, Set
Time and Check programming.
Disable
Press the 1 key to display the following screen:
Press the * key to display detectors, the # key to display modules, enter the device address, then press
the
ENTER
key. A typical display is shown below:
A point is then displayed on the screen similar to a Point Edit display but with the current status label
(ENABLE shown) blinking. The current status label may show: NORMAL, TROUBL, DISABL,
ENABLE, ALARM, ACTIVE, PROGRM, TEST 01, ON, OFF. The status label can be changed to
DISABL or back to its present status by pressing the up or down arrow keys. The disable status is
entered/stored in memory by pressing the
ENTER
key. The display then returns to the DISABLE/
ENABLE screen shown above. The operator may then enter a new point number, or may press up/down
to bring up the next lower/higher address point.
Note: The control panel only disables initiating devices that are in alarm or control points that are ON occurs after the
SYSTEM RESET
key is pressed.
All disabled points will scroll on the LCD display and the system will remain in trouble until all
programmed points are enabled.
