NTI ENTERPRISE ENVIRONMENT MONITORING SYSTEM
2
The ENVIROMUX-5D Medium Enterprise Environment Monitoring System and ENVIROMUX-2D Small Enterprise
Environment Monitoring System have almost the same functionality as the ENVIROMUX-16D, just fewer connection points.
ENVIROMUX-16D vs. ENVIROMUX-5D vs. ENVIROMUX-2D
Feature Differences
Feature ENVIROMUX-16D ENVIROMUX-5D ENVIROMUX-2D
Internal Sensors
3
2 0
Temperature
9
9
N/A
Humidity
9 9
N/A
Battery
9
only for ENVIROMUX-5DB only for ENVIROMUX-2DB
RJ45 Sensor Ports
16 5 2
Digital Inputs
8
5 5
12VDC provided on Digital
Inputs
9
N/A N/A
Output Relays
4
2 1
Auxiliary (12V) Power
Terminal
9 9 9
Alerts
8 Methods
8 Methods 6 Methods
Alarm Silence/Test Button
9
9
N/A
Control Methods
6 Methods 5 Methods** 5 Methods**
USB Ports for Modem and
Data Logging
4 4 2
Front Panel LEDs
6 2 2
Backup Battery
9 (1 Hour)
Optional (2 Hour)
(ENVIROMUX-5DB)
Optional (2 Hour)
(ENVIROMUX-2DB)
Power
• 110 or 220 VAC at 50 or 60
Hz via IEC connector. 65W
• Options: dual power, 24VDC,
24VDC dual power, 48VDC,
48VDC dual power
110 or 220 VAC at 50 or 60
Hz via AC adapter. 3A
Optional Dual Power
48VDC, 48VDC dual power
110 or 220 VAC at 50 or 60
Hz via AC adapter / 3A
Optional Dual Power
* No dedicated alarm beacon/siren terminals although they CAN be connected to ENVIROMUX-2D
** ENVIROMUX-5D / -2D do not include an RS232 port for console control, but a USB Type B “Console” port (and
drivers) is provided for this control method.
N/A= Not Available
Options:
¾ ENVIROMUX-16D
¾ Dual Power – ENVIROMUX with two power connections for optional redundant power source connection (see
page 19) - add “DP” to the model number (i.e. ENVIROMUX-16DDP)
¾ DC Power - to install the ENVIROMUX in a Telecom environment (see page 20). Add “-48V” or “-24V” to the
model number (i.e. ENVIROMUX-16D-48V / -24V)
* For -48V model, converter accepts 36~72VDC (48VDC nominal), positive or negative polarity.
* For -24V model, converter accepts 18~36VDC (24VDC nominal), positive or negative polarity.
* 3-pole screw terminal for connecting 48V / 24V input
¾ SFP Socket- ENVIROMUX with socket for SFP module to provide alternative Ethernet connection method- add
“F” to the model number (i.e. ENVIROMUX-16DF)
¾ ENVIROMUX-5D /-2D
¾ DIN Rail Mounting- ENVIROMUX-5D or -2D can be ordered with a DIN rail mounting bracket- Add “D” to the
part number (i.e. ENVIROMUX-5D-D)
¾ Battery Backup- ENVIROMUX-5D or -2D can be ordered with battery backup support and DC power
monitoring installed, providing up to 2.3 hours of operation in the event of a power failure- to order, add “B” to
the part number (i.e. ENVIROMUX-5DB)
¾ 48V/24V/12V/9V Power Option- ENVIROMUX-5D-48V can be ordered with power connections for 18-72VDC
(24 or 48VDC nominal) in addition to jacks for 9-12VDC AC adapter connection. For dual 48V connections, just
add “DP” to the model number (i.e. ENVIROMUX-5D-48VDP).
