NOTE: UNLESS OTHERWISE SPECIFIED.
1. R=.015
R
E
V
I
S
I
O
N
H
I
S
T
O
R
Y
REV
ECR NO.
DATE RELEASED BY
MATERIAL LENGTH
FINISH
NEW TECH MACHINERY
CORP.
DRAWN BY
DATE
CHECK BY
DATE
TOLERANCES PART NAME
SHEET
PART NUMBER
REVISION
0
ELECTRICAL ASSEMBLY
PLC-380-000
1
2
OF
.XX =
`
.01
.XXX =
`
.005
FRACTION =
`
1/32"
ANGLE =
`
1/2
~
BT
01-27-2011
AJB
10/25/2011
-
NONE
0 R-1757 10/25/2011 AJB
SEE BOM
Parts List
TITLEPART NUMBERQTYITEM
GROMMET, 3/4" ID, 1-1/2" ODELC-300-13811
HEX HEAD CAP SCREW, 1/4-20 x 1" LG.FAS-HC5-11812
HEX HEAD CAP SCREW, 1/4-20 x 2" LG.FAS-HC5-27823
NYLOC HEX NUT, #1/4-20FAS-NUY-188
34
SCREW, PAN HEAD, 8 x 1/2", PHIL, SELF-TAPPINGFAS-SRM-20725
WASHER, FLAT, 1/4" SAEFAS-WSF-26046
CONTROL BOX ASSEMBLYPLC-381-0001
7
REMOTE PUSH BUTTON BOXPLC-382-00018
TOS LIMIT SWITCHES
HYDRAULIC
CONTROL VALVES
REMOTE SWITCH
GAS MOTOR
-OR-
ELECTRIC MOTOR
BACK VIEW OF
CONTROL BOX
OVERRIDE
PRESSURE SWITCH
INSTALL GROMMET
IN MACHINE COVER
AS REQUIRED
8
1
7
3 4 6
2 4 6
8
1
2
3
4
5
6
7
RIGHT
LEFT
5
