CHAPTER 1
SSQ SPECIFICATIONS
1
SPECIFICATIONS
SSQ Dimensions: Length-13’ 7” (4.1m)
Width-5’ (1.5m)
Height-4’ 3” (1.3m) w/Over Head Rack
1’ 10” (.6m) w/o Over Head Rack
Weight-2200 lbs. (1450kg)
SSQ on Trailer: Length-17’ 6” (5.3m)
Width-7’ (2.1m)
Height-6’ 3” (1.9m) with reel
Weight-4800 lbs. (2200kg)
Speed: 75 ft./min. Approx. (23m/min.) Approx.
Drive: Hydraulic via chain, sprocket and gear using16 polyurethane drive
rollers.
Shear: Hydraulically Powered, Infinitely adjustable, hardened tool steel dies
and blades w/Panel Recognition Proximity Sensor
Hydraulic Fluid: 18 Gallons - 32AW
Coil Width: 15” to 30” (380mm to 760mm) Note: 30” coil width requires
Expandable Arbor or Remote De-coiler Stand.
Materials Formed: Painted Steel 30ga. to 22ga. (.3mm to .8mm)
Painted, Galvanized, Aluminized
Painted Aluminum .019” to .040” (.5mm to 1.0mm)
Copper 16 oz. to 20 oz. ¾ Hard
(.5mm to .7mm)
Turne-Coat Stainless Steel 26ga. (.5mm)
Controls: Standard: 12v Manual Control Box w/Length Control
Limit Switch
Optional: Computer Batch and Length Control
