CHAPTER 14
WIDTH CHANGE PROCEDURE
48
29. Make sure that one of the points of the top shear blade is inboard of the
vertical portion of the male leg. This part of the leg should be cut with the
angle or rake of the blade to cut in a scissor action against the vertical die. See
TOP SHEAR BLADE ADJUSTMENT (Figure 19 & Figure 20) if
adjustment is necessary.
30. Start the machine and press the shear down button to cut off the panel, then
jog the material through the shear again and stop.
31. Inspect the two cuts and adjust the dies as necessary until an acceptable cut is
made. Again, TURN THE MACHINE OFF BEFORE MAKING ANY
ADJUSTMENTS.
32. Once you are satisfied with the cut being made, you are ready to run panel.
