Page #5 background image
Introduction
MPC5777M Microcontroller Data Sheet, Rev. 6
NXP Semiconductors 5
CRC channels 2
Software watchdog timer
(Task SWT/Safety SWT)
4 (3/1)
Core Nexus class 3+
Sequence processing unit (SPU) Yes
Debug and calibration interface (DCI) / run control
module
Yes
System SRAM 404 KB
Flash memory 8640 KB
Flash memory fetch accelerator 4 256 bit
Data flash memory (EEPROM) 8 64 KB
+ 2 16 KB
Flash memory overlay RAM 16 KB
External bus 32 bit
Calibration interface 64-bit IPS Slave
DMA channels 2 64
DMA Nexus Class 3+
LINFlex (UART/MSC) 6 (3/3)
MCAN/TTCAN 4/1
DSPI
(SPI/MSC/sync SCI)
8 (4/3/1)
Microsecond bus downlink Yes
SENT bus 15
I
2
C 2
PSI5 bus 5
PSI5-S UART-to-PSI5 interface Yes
FlexRay 2 dual channel
Ethernet MII / RMII
Zipwire

(SIPI / LFAST
2
) Interprocessor Communication
Interface
High speed
System timers 8 PIT channels
3 AUTOSAR
®
(STM)
64-bit PIT
BOSCH
GTM Timer
3
Yes
GTM RAM 58 KB
Interrupt controller 727 sources
ADC (SAR) 12
Table 1. MPC5777M feature (continued)
Feature MPC5777M
