1 Introduction
1.1 Document overview
This document provides electrical specifications, pin assignments, and package diagrams for the MPC5777M series of
microcontroller units (MCUs). For functional characteristics, see the MPC5777M Microcontroller Reference Manual.
1.2 Description
This family of MCUs is targeted at automotive powertrain controller and chassis control applications from single cylinder
motorcycles at the very bottom end; through 4 to 8 cylinder gasoline and diesel engines; transmission control; steering and
breaking applications; to high end hybrid and advanced combustion systems at the top end.
Many of the applications are considered to be functionally safe and the family is designed to achieve ISO26262 ASIL-D
compliance.
1.3 Device feature
Table 1. MPC5777M feature
Feature MPC5777M
Process 55 nm
Main processor Core e200z7
Number of main cores 2
Number of checker cores 1
Local RAM (per main core) 16 KB Instruction
64 KB Data
Single precision floating point Yes
LSP No
VLE Yes
Cache 16 KB Instruction
4 KB Data
I/O processor Core e200z4
Local RAM 16 KB instruction
64 KB Data
Single precision floating point Yes
LSP Yes
VLE Yes
Cache 8 KB instruction
Main processor frequency 300 MHz
1
I/O processor frequency 200 MHz
MMU entries 0
MPU Yes
Semaphores Yes
