180 Océ TDS400 User Manual
Paper jam in the fuser section
Caution: Open the fuser only to remove the paper after a media jam.
Because of hot surfaces the operator always has to be cautious and wear
heat-protective gloves, when he removes material in the fuser section.
▼ How to clear a jam in the fuser section
1
Turn off the printer.
2 Loosen the screw at the left hand side of the machine and open the cover (see
Figure 94).
[94] Unscrew the knurled nut to open the cover
3 Lift the green handle (see Figure 95).
[95] Lift the green handle
4 Open the fuser unit (see Figure 96).
