44473001TH Re
v
.1
122 /
Oki Data CONFIDENTIAL
4.REPLA
CEMENT OF P
ARTS
â‘
-3 44527301PP Slider-Hinge (FB)
Slider-Hinge (FB)
EM-D110 Class E
Apply a large amount of MOL
YK
O
TE
(EM-D110) to the sliding surface
.
(hatched areas)
â‘¡
44659101P
A Gear-Idle-Assy
Gear-Planet
SF-133 Class C
Apply a normal amount of HANARL
(SF-133) to the hatched area.
(all circumference of post)
Leave it for about 3minutes (drying time) after painting HANARL SF-133,
and then assemble the Gear-Idle-Assy.
121
