44473001TH Re
v
.1
258 /
Oki Data CONFIDENTIAL
8.
CONNECTION DIAGRAMS
8.1
Chec
k of resistance v
alues
Unit
Circuit diagram and composition
Part drawing
Resistance v
alue
T
ranspor
t belt motor
M
1
2
3
4
Between pins 1 and 2:
3.4
Between pins 3 and 4:
3.4
ID motor
IP2
Both ends of IP2:
1
or less
