44473001TH Re
v
.1
121 /
Oki Data CONFIDENTIAL
4.REPLA
CEMENT OF P
ARTS
â‘
-1 44597101PP Cam-Hinge (FB)
4.3.1
ADF
Cam-Hinge (FB)
EM-D110 Class E
Apply a large amount of MOLYKOTE
(EM-D110) to the hatched area.
Grease lump possibility
Application Direction
â‘
-2 44527201PP Slider Inner
EM-D110 Class A
Apply a small amount of
MOLYKOTE (EM-D110) to the
surface 2 places of projection.
EM-D110 Class A
Apply a small amount of
MOLYKOTE (EM-D110) to the
surface 2 places of projection.
Slider-Inner
120
122
Table of Contents
