44473001TH Rev.1
81 /
Oki Data CONFIDENTIAL
3. MFP INSTALLATION
3.8 Connection Procedures
<USB Connection>
Prepare a USB Cable.
Note!
•
T
h
e cable of the MFP is not attached. Users should buy seperately.
•
Ob
tain the cable of USB specification by yourself.
•
Use the USB cable of Hi-Speed specification in case the connection is to be
made using "HI-Speed" mode of USB2.0.
(2
) Plug one end of the USB cable into the USB connection on the back of the MFP.
(3) Hook the Ethernet cable on the hook of the MFP.
(4) Attach the interface cover.
Switch off the power of the
MFP
and computer.
Memo Although the USB cable can be connected or removed with the switch of the
computer and printer on, switch off the power of the MFP at this step in order
to ensure installation of the MFP driver and USB driver later.
Connect the
MFP
with the computer.
(1) Remove the interface cover on the right side of the machine while pressing the lock
button.
Lock button
Interface cover
To Next Page
