4.REPLACEMENT OF PARTS
③
-3 Portion I
EM-30LP Class C
Apply a normal amount of MOLYKOTE
(EM-30LP) to the hatched area.
(all circumference of shaft)
Bearing-Shaft
③
-4 Portion B, C, D and E
SF-133 Class C
Apply a normal amount of HANARL
(SF-133) to the hatched area.
(all circumference of post)
SF-133 Class C
Apply a normal amount of HANARL
(SF-133) to the hatched area.
(all circumference of the sliding surfaces)
EM-30LP Class C
Apply a normal amount of MOLYKOTE
(EM-30LP) to the hatched area.
(all circumference of post)
Frame-ADF
Leave it for about 3minutes (drying time) after painting HANARL SF-133, and then
assemble the ADF-Assy.
