44473001TH Rev.1
56 /
Oki Data CONFIDENTIAL
2. DESCRIPTION OF OPERATION
2.3.2 Document table structure
2.3.2.1 Overview
Flatbed unit consist of Cover-Top-Assy, Frame-Bottom-Assy, Carriage-Assy and Flatbed drive
block.
The lamp (LED) is located on top of the Carriage-Assy. The light imadiated by the lamp (LED)
rodrenze in this order and reaches the CIMOS Sensor.
2.3.2.2 Exposure block
1. Lamp
LED(R,G,B) is used toirradiate light to document
2. Rod lens
The reflected light from document is again reflected to the CIMOS sensor
To Next Page
