44473001TH Rev.1
84 /
Oki Data CONFIDENTIAL
3. MFP INSTALLATION
<TEL cable/ Line Cable Connection>
Prepare the TEL cable and Line cable.
Connecting for Fax only
(1) Plug one end of the supplied telephone cable into the LINE connection of the MFP
and the other end into an active telephone jack.
(2) Attach the supplied connector cover to the TEL connection of the MFP.
Connecting for Fax and Telephone
(1) Plug one end of the supplied telephone cable into the LINE connection of the MFP
and the other end into an active telephone jack.
(2) Plug the telephone’s cable into the TEL connection of the MFP.
To Next Page
