5238-E P-229
SECTION 8 LATHE AUTO-PROGRAMMING FUNCTION (LAP)
(1) ID machining
The cutting tool may interfere with the workpiece. Correct the program as necessary, for
example, change the AP starting point.
From AP Mode IV to AP Mode I
LE33013R0301000310003
From AP Mode V to AP Mode II
LE33013R0301000310004
AP starting point
Cs
AP starting point
Cs
In AP Mode IV In AP Mode I
AP starting point
Cs
In AP Mode IV In AP Mode II
Cs AP starting point
