5238-E P-339
SECTION 15 APPENDIX
M80 Overcut advance ✩
M81 Overcut retract ✩
M82
M83 Chuck clamp
M84 Chuck unclamp
M85 No return to the cutting starting point after the completion of rough turning cycle (LAP) ✩
M86 Turret indexing direction: Clockwise (reverse)
M87 Cancel of M86
M88 Air blower OFF
M89 Air blower ON
M90 Cover close ✩
M91 Cover open ✩
M92 Bar feeder retract ✩
M93 Bar feeder advance ✩
M94 Loader loading ✩
M95 Loader unloading ✩
M96 Parts catcher for sub spindle retract ✩
M97 Parts catcher for sub spindle forward ✩
M98 Tailstock spindle thrust low
M99 Tailstock spindle thrust high
M100 Waiting for synchronization command
M101 External M signal ✩
M102 External M signal ✩
M103 External M signal ✩
M104 External M signal ✩
M105 External M signal ✩
M106 External M signal ✩
M107 External M signal ✩
M108 External M signal ✩
M109 Cancel of M110 ✩
M110 C-axis joint
M111 Automatic zero point setting for pick-off spindle ✩
M112 M-tool spindle on the 3rd turret stop ✩
M113 M-tool spindle on the 3rd turret forward rotation ✩
M114 M-tool spindle on the 3rd turret reverse rotation ✩
M115 Unloader open ✩
M116 Unloader close ✩
M117 Sensor head advance ✩
M118 Sensor head retract ✩
M119 Work count special ✩
M120 No work ✩
M121 Steadyrest open/close
M122 Steady rest retract ✩
M123 Steady rest forward ✩
M Code Contents
To Next Page
