Introduction 13
Introduction
This manual provides instructions for assembling, installing, and operating the
COBRA scanner.
The COBRA scanner is a manual weld inspection scanner for the non destructive
inspection of pipes with outside diameters ranging from 21.3 mm to 114.3 mm
(0.84 in. to 4.50 in.). The COBRA scanner typically uses the OmniScan (models can
vary) with a 16:64 or a 16:128 module, and the OmniScan MXU software to inspect
circumferential welds on small-diameter pipes (see Figure i-2 on page 13).
Figure i-2 The OmniScan MX2 and the COBRA scanner
Note: Instrument model and connector type can vary.
