DMTA-20006-01EN, Rev. B, February 2014
Labels and Symbols
1
Labels and Symbols
Marking locations of the instrument are shown in Figure i-1 on page 1. If any or all of
the labels or symbols are missing or illegible, please contact Olympus. The
descriptions of the symbols are provided in Table 1 on page 2.
Figure i-1 Marking locations
Symbols
Serial number
Symbols
Encoder resolution
32.08 counts/mm
