5.2 Connector Reference
COBRA scanners sold after July 2013 come standard with the LEMO connector which
is compatible with the OmniScan MX2 and SX instruments. For use with a different
instrument, an optional adaptor is required (see Table 12 on page 62).
Table 11 Operating environment specifications
Parameter Va lu e
Operating temperature 5 °C to 50 °C (41 °F to 122 °F)
Storage temperature ‒30 °C to 60 °C (‒22 °F to 140 °F)
Relative humidity (RH) Max. 80 % RH noncondensing
Wet location Yes
Altitude Up to 2000 m
Outdoor use Yes
Pollution level 1
IP rating Waterproof (designed to meet IP67)
Table 12 Required encoder cable adaptor
Scanner
Connector
Instrument
OmniScan MX OmniScan MX2 OmniScan SX
TomoScan
FOCUS LT
LEMO (from July
2013 onward)
Omni-A-ADP27
——
C1-LF-BXM-0.3M
DE15 (Prior to
July 2013)
—
Omni-A2-ADP20 Omni-A2-ADP20
C1-DE15F-BXM-
0.30M
