DMTA-20006-01EN, Rev. B, February 2014
Chapter 1
20
1.3 Required Tools for Scanner Setup
The few tools required for the assembly, reconfiguration, and adjustment of the
scanner are included with the COBRA scanner (see Table 4 on page 20 and Figure 1-6
on page 20).
Figure 1-6 Tools included with the COBRA scanner
Table 4 Required tools (included with the scanner)
Quantity Description
1 T6 Torx screw driver
1 2.5 mm hexagonal screw driver
1 Phillips #0 screw driver
1 Loom installation tool (to insert cables and tubes in the protective sleeve)
