Olympus COBRA - Probe and Setup Specifications

DMTA-20006-01EN, Rev. B, February 2014
Chapter 5 64
5.3 Probe Specifications
5.4 Scanner Setup Charts
The scanner setup charts specify how to configure the scanner for a specific pipe
outside diameter (see Table 15 on page 65 and Table 16 on page 66).
13 N/A Not used
14 N/A Not used
15 N/A Not used
16 GND Ground
Case Shield Ground earthing
Table 14 Standard phased array probe specifications
Parameter Va lu e
Part number 7.5CCEV35-A15-P-2.5-OM
Frequency 7.5 MHz
Number of elements 16
Pitch 0.5 mm
Elevation 10 mm
Corresponding wedge SA15
Cable length 2.5 m
Connector type OmniScan
Elevation curvature radius 35 mm
Table 13 OmniScan MX2 pinout for the scanner interface
LEMO connector (continued)
Pin Signal Description
